General & Performance Specs

Engine: 4-cylinder diesel (e.g. Kubota V2607 / Bobcat D24 depending on spec)


Power: ~ 66 hp (49.2 kW)


Displacement: ~ 2392–2600 cm³ ( 2.4–2.6 L)


Fuel tank capacity: ~ 138.2 L

Rated operating capacity (35% tipping load, ISO): ~ 971 kg ( 2140–2200 lb)


Tipping load (ISO): ~ 2774–2834 kg ( 6,000–6,250 lb) depending on spec / region.


Hydraulic pump flow (standard): 64.7 L/min ( 17.1 gal/min)


Hydraulic pump flow (high-flow option): up to 101.1 L/min


Hydraulic relief pressure (quick-couplers): ~ 23.8–24.5 MPa ( 3,500 psi)


Travel speed: up to ~ 16.7 km/h ( 10.4 mph) with optional high-speed drive.

Weight, Size & Dimensions

Operating weight: ~ 3,500–3,600 kg ( 7,700–7,900 lb) depending on version.


Width (over tracks): ~ 1.70 m ( 67 in)

Length (with bucket): ~ 3.38 m ( 133 in)

Height (top of cab / ROPS): ~ 1.98 m ( 77.8 in)


Bucket width: ~ 1.73 m ( 5.68 ft)


Bucket capacity: ~ 0.93 m³ ( 246 gallons equivalent)
