• Equipment:
• Manufacturer: Shred-Tech
• Model: ST-50
• Type: 2-Shaft Shredder

• Dimensions:
• Cutting Chamber:
• 40 in × 21 in
• 50 in × 21 in
• Machine Length:
• 110 in
• 120 in
• Machine Width: 45 in
• Machine Height: 107 in
• Floor Space: 34–38 sq ft
• Discharge Height: 40 in
• Hopper Height: 44 in
• Hopper Opening:
• 40 in × 40 in
• 50 in × 40 in

• Weight:
• Machine Weight: 5,200–5,500 lbs

• Power & Drive:
• Drive Type: Electric
• Number of Motors: 2
• Motor Power: 40–50 HP
• Voltage: 208–600 V
• Phase: 3
• Frequency: 50/60 Hz

• Cutting Assembly:
• Knife Thickness Options:
• 5/8 in
• 7/8 in
• 1 3/16 in
• Number of Knives:
• 40
• 60
• 80
• Knife Diameter: 10 in
• Hex Shaft Size: 3 3/8 in
• Distance Between Shafts: 7 1/2 in
