Powerfrag PFD-150-180 | 60" x 72" Drive system not included


• Equipment:
• Manufacturer: Magnapower Equipment Ltd
• Product Line: POWERFRAG®
• Model: PFD-150-180
• Type: Frag Drum Magnet
• Condition: New

• Dimensions:
• Drum Diameter: 60 in (1,500 mm)
• Face Width: 72 in (1,800 mm)

• Magnetic System:
• Type: Deep-Field Hybrid Permanent Magnet
• Magnetic Field Coverage: Approximately 80° of Drum Surface
• Power Requirement: None (Permanent Magnetic System)
• Magnet Alignment: Shaft Arrow Indicates Magnet Center; Flats Aligned at 6 and 12 O'Clock Positions

• Mechanical Construction:
• Bearings: Cooper Split Bearings
• Wear Cover: Replaceable Manganese Steel Wear Skin with Cleats
• Side Rings: Manganese Steel Anti-Spillage Rings
• Base Frame: Pre-Aligned with Guarded Chain Gear Drive

• Drive & Electrical:
• Drive System Included: No
• Required Drive: External Gear-Reduced Motor
• Drum Rotation Sensor: 24 VDC Proximity Sensor (One Pulse per Rotation)
• Typical Drive Motor: SEW Geared Motor (Application Dependent)

• Material Feed:
• Bottom-Fed
• Middle-Fed

• Applications:
• Auto Shredder Residue (ASR) Processing
• Ferrous Scrap Metal Recovery
• Heavy-Duty Recycling
• Waste Sorting
• Continuous Ferrous Metal Separation

• Features:
• Continuous Automatic Ferrous Metal Removal
• Permanent Magnetic System (No Rectifier Required)
• Heavy-Duty Lift Shackles for Installation
• Transport Beams and Packers for Shipping Security (Removed During Installation)
