Key Specifications

Nominal Bale Size: 72″ W × 30″ D × 48″ H


Bale Weight (OCC): Up to 1,600 lbs


Bale Volume: 60 cu ft


Number of Bale Tie Slots: 7


Compact Force (lbs): Normal ~84,667 lbs; Maximum ~96,213 lbs


Platen Pressure: ~43 PSI


Average Cycle Time: ~67 seconds


Loading Height: 49.50″


Hydraulic / Electrical & Mechanical

Motor: 20 HP, 3-phase


Voltage options (3 phase): 208 V full load amps ~59 A; 230 V ~54 A; 480 V ~27 A


Pump Flow: ~15 GPM


Normal System Pressure: ~2,200 PSI; Maximum ~2,500 PSI


Cylinder: Bore 7″ × Stroke 60″


Hydraulic Tank Capacity: ~30 gallons
