Manufacturer: Eldan Recycling A/S (Denmark)

Type / model: GRA F952

Serial / fabrication no.: 93-10630

Motor power: 75 kW (approx. 100 HP)

Electrical:

Voltage: 3 x 440 V

Frequency: 60 Hz

Phase: 3-Phase

Typical / reference specifications (eldan gra f: series granulator)

(These are standard for the GRA F952 size class and commonly used for quoting unless the OEM spec sheet states otherwise.)

Machine type: Heavy-duty granulator / refiner

Applications:

E-scrap

Aluminum and non: ferrous scrap

Radiators

Small electric motors

Wire/chop prep after pre: shredding

Rotor width: ~950 mm ( 37 in)

Rotor diameter: 950 mm

Cutting System:

Solid steel rotor

Replaceable knives

Screen: controlled output size

Typical Throughput:

1,500 – 3,000 kg/hr (material dependent)

Discharge Size:

Controlled by screen (commonly 10–40 mm)

Construction:

Welded heavy steel housing

Direct: drive or belt-driven (varies by year/build)

Approx. Weight:

7,500 – 9,000 kg (16,500 – 20,000 lb), depending on configuration

Cooling:

Air: cooled motor

Model: GRA F952
Type: Single-shaft high speed fine granulator
Motor speed: 1480 RPM
Rotor speed: 475 RPM
Knife configuration: 12 flying / 4 static
Capacity: Up to 3500 kg/hour
Weight: Approx. 4400 kg
Dimensions: 1940 x 1960 x 2800 mm
Applications: Tires, cables, aluminum scrap, plastics
Features: Adjustable knife clearance, regrindable knives, hydraulically operated inlet hopper, exchangeable wear parts, interchangeable screens for different output sizes
