Engine tier: Tier 4 Final
Max digger reach: 32' 6"
Max digging depth: 22' 0"
Max Digging Height 31' 11"
Air conditioning: Yes
Overall height (boom): 9.78 ft
Overall height (cab): 10.04 ft
Overall length: 31.5
Overall length of crawler: 14.6 ft
Overall width: 10'5" (800mm shoes)

Engine power: 160 HP (119 kW) @ 2,000 RPM (SAE Net)
Operating weight: 49,400 lbs (31.5" shoes)
Bucket capacity: 0.92-1.22 cu yd (SAE Heaped)
Max dumping clearance: 22'8"
Tail swing radius: 9'7"
Track gauge: 7'10"
Ground pressure: 4.5-6.5 psi (shoe width dependent)
