Specification V-7230 HD
Bale Size 72″ wide × 30″ deep × 48″ high
Cylinder (Hydraulics) 6″ bore × 3.5″ rod × 48″ stroke
Motor 10 HP, 3-phase (208/230/460 V)
Pump Flow ~10.5 GPM
System Pressure Working pressure ~2,000 psi; max ~2,200 psi
Platen (Compression) Force ~62,200 lbs (on spec sheet)
Cycle Time ~56 seconds per bale
Feed Opening 72″ wide × 25″ high (feed gate)
Bale Weight (OCC) Up to ~1,400 lbs
Baler Weight (Dry) ~5,400 lbs (per spec sheet)
Overall Dimensions According to Marathons specs: ~100″ wide × 44.5″ deep × 142″ tall (per older spec sheets)
